HiFive Premier P550 Development Board
Powered by the ESWIN EIC7700X SoC with a SiFive Quad-Core P550 64-bit Out-of-Order CPU cluster, this board offers exceptional performance and flexibility, enabling developers to create high-performance RISC-V applications and bring their projects to life.
HiFive Premier P550 Key Features:
- Quad-core SiFive P550 - Performance CPU cores running @ 1.4GHz
- 16GB and 32GB Samsung/Micron LPDDR5 + 128GB Samsung eMMC
- Full featured PC IO
- Ubuntu 24.04 Pre-Installed
- Full featured Ubuntu 24.04
- 6.6 Kernel
- OTA updates
- Vibrant Community Support
HiFive Premier P550 – Details:
SoC
ESWIN EIC7700X SoC featuring:
- SiFive quad-core P550 CPU cores
- Imagination AXM-8-256 onboard GPU
- HW accelerated video encoding: up to 8K@25fps (currently not supported in software)
- HW accelerated video decoding: up to 8K@50fps (currently not supported in software)
- HW accelerated AI NPU with ~20 TOPS (currently not supported in software)
Networking
- 2 10/100/1000 Ethernet RJ45 connectors
- 1 Ethernet RJ45 connector for remote board management using dedicated MCU
- 1 M.2 Key E connector for Wi-Fi / Bluetooth module (Interface via SDIO / UART)
Expansion Capabilities
- 1 PCI Express Gen 3 x4 via a PCIe x16 slot
- 2 Stacked USB 3.2 Gen 1 Type-A Connectors
- 1 USB 19-pin male connector to support 2 USB 3.2 Gen 1 connectors on front panel
- 1 USB type-E connector to support 1 USB 3.2 Gen Type-C connector on front panel
- 1 JTAG Header
- 1 SATA 3 connector (6Gb/s)
- 1 microSD card connector
- 1 USB Type-C (USB2 only) connector for debug UART/JTAG support through FT4232H
- 1 HDMI 2.0 connector
- Mini-ITX case compliant Front Panel Connector
- 1 CR1220 battery holder for Real Time Clock
- 3 fan headers
- 1 header for audio interface (front panel stereo line-out and line-in / microphone signals)
- 1 rear panel stereo jack with microphone input
- 1 40-pin Peripheral I/O Header (1 I2C, 1x QSPI, 1x UART, 16x GPIO)
Note: Board requires standard ATX power supply – please check here for recommended model numbers
PCIe Gen3
High speed interface
Quad Core P550
SiFive RISC-V Processor Cores
16GB LPDDR5
128GB eMMC Memory
USB 3.2
I/O Connectivity
Dimensions
USAGE
HiFive Premier P550
Documentation
HiFive Premier P550 Product Brief
HiFive Premier P550 Getting Started Guide
[EN] [FR] [ES] [IT] [PT] [DE] [PL] [NL] [SV] [JP] [ZH] [KR]
HiFive Premier P550 Software Reference Manual
The HiFive Premier P550 Advantage
If you’re a software developer, a kernel developer, are prototyping RISC-V products with performance in mind, or simply want the highest performance RISC-V experience today, this is the board for you.
